10kW Residential Solar Panel System : Avg Cost | Savings | Payback period
Why 10kW Residential Solar System?
- 10kW solar systems in Sydney are a great investment for Australian homes with significant electricity demand or for businesses with only modest electricity requirements.
- This 10kW solar system can be all you need to get started before expanding your solar system if you don’t mind making a minor upfront cost. As a 10kW solar system generates 40 units on average each day.
- If you’re considering installing a 10kW solar system in your home, All In One Solar Systems covers (almost) all you need to know, including costs, energy savings and return.
10kW ON-GRID SOLAR SYSTEM SPECIFICATIONS
| Particulars | Description |
|---|---|
|
Solar Power Plant |
10 kW
|
|
Solar Panel in Watt |
415 watt
|
|
Solar Panel Qty |
24 units
|
|
Solar Structure |
10 KW
|
|
On Grid Solar Inverter |
8 KW
|
|
MC4 Connector |
6 Pair
|
|
DC Junction Box |
1 Nos
|
|
AC Junction Box |
1 Nos
|
|
DC Cable |
90 Mtr
|
|
AC Cable |
40 Mtr
|
|
Space required |
80 meter square
|
|
Solar Accessories |
Fasteners, Cable Tie , Crimping Tool, Earthing Kit, Lighting Arresstor
|
|
Average Generation |
* 40 Units Per Day.
|
|
Warranty |
5 years for Complete System.25 years for Solar Panels.
|
|
Delivery & Installation |
As per quoted date in order
|
|
Solar Net-Metering |
Yes, Solar Net-Metering is applicable on this system.
|
10kW ON-GRID SOLAR SYSTEM SPECIFICATIONS
| Particulars | Description |
|---|---|
|
Solar Power Plant |
10 kW
|
|
Solar Panel in Watt |
415 watt
|
|
Solar Panel Qty |
24 units
|
|
Solar Structure |
8 KW
|
|
Off Grid Solar Inverter |
10 KVA |
|
Solar Battery |
10 units
|
|
Junction Box |
1 Nos
|
|
DC Cable |
90 Mtr
|
|
AC Cable |
60 Mtr
|
|
Space required |
80 meter square
|
|
Solar Accessories |
Fasteners, Cable Tie , Crimping Tool, Earthing Kit, Lighting Arresstor
|
|
Average Generation |
* 40 Units Per Day.
|
|
Warranty |
5 years for Complete System.25 years for Solar Panels.
|
|
Delivery & Installation |
As per quoted date in order
|
|
Solar Net-Metering |
Yes, Solar Net-Metering is applicable on this system.
|
Recommended load on10kW Hybrid solar system
| Recommended Load | Load | Back-up Time |
|---|---|---|
|
* 8 LED Lights + 8 Fan + 2 ton AC (2 nos)+ Fridge+1 TV+ Washing Machine+1 Cooler |
8000 watt |
4 Hours
|
|
* 12 LED Lights + 6 Fan + 1 ton AC(2 nos)+ Cooler+ Fridge+ 1 TV |
6000 watt |
6 Hours
|
|
* 12 LEDs + 10 Fan + Fridge+ 1 TV+ Washing Machine+1 Cooler |
3000 watt |
10 Hours
|
Frequently Ask Questions about 6.6 kW Solar PV System
Checkout some important questions that you need to know for 6.6 kW Solar PV System.
- We have been keeping tabs on residential solar system prices for a while now. Based on this data, we predict that the cost of a typical 10 kW solar system will be approximately $0.91 per watt, or $9000 once the federal STC subsidy is subtracted.
- On the other hand, the cost of solar systems varies greatly. A 10 kW solar PV system using more cost-effective, lower-end components will be less expensive, but premium options will cost more.
- A 10kW system will require 25–30 solar panels (typically 1.7 metres by 1 metres in size) and 80 metres sq. of roof space. The majority of household solar panels have a 330W–400W output rating.
- More efficient solar panels take up less roof space but frequently cost more since many employ newer technologies.
- 10kW solar systems are on the large side for residential installations (where 5kW to 6.6kW is much more common).
- As already said, homes that use a lot of electricity during the day are best suited for 10kW systems (or businesses with about 40kWh of daytime usage).
- They might also be a good size for homes that want to disconnect from the grid but only have a moderate need for power (see "Can I disconnect from the grid with a 10kW solar system?").
- You can use the table below to assess whether a 10kW system is suitable for your needs or whether a larger system would be more suited. Our advice is that you consume at least 30% of your energy.
- Most solar panel buyers assess the performance of their panels using the payback time, or the number of years it will take for the system to pay for itself in energy bill savings and feed-in tariff credits.
- For 10 kW solar systems, typical payback times and savings per year in a few Australian major cities are 3–6 years and $1500-$2500 savings per year
